Descripción
RITMO RAPIDO, SALIDAS EPICAS
EMPUJAR SOBRE EL SENDERO PARA ARRIBA Y PARA ABAJO
CAZANDO RECORDS PERSONALES
La Rift Zone es nuestra bicicleta MultiTrac más orientada a la velocidad, creada para el ciclista que busca la velocidad y la capacidad de balanceo de las ruedas de 29” en un paquete apto para senderos. La geometría de sendero larga, baja y relajada es más agresiva que la de una bicicleta de carreras XC para brindar más control a máxima velocidad y más diversión al perseguir segundos.
ESPECIFICACIONES TÉCNICAS
- Cuadro: Unidirectional Carbono Fiber Front Triangle, Series 4 Alloy Rear End, 29” Wheels, 125mm Travel, MultiTrac Suspension Platform, 148x12mm Boost Thru-Axle, 73mm Threaded BB w/ ISCG05 Tabs
- Horquilla: Fox Performance 34 Float, 130mm Travel, 3-Position Micro Adjust Compression Adjustment, Rebound Adjustment, 110x15mm Kabolt Axle, 44mm Offset
- Shock trasero: Fox Float with Reservoir, Performance Series, EVOL Air Spring, Climb Switch, Rebound Adjustment, Custom Tune, 210x50mm, M8x30mm Top, M8x25mm Bottom
- Llantas: Marin Aluminum Double Wall, 29mm Inner, Welded Joint, Disc Specific, Tubeless Compatible
- Maza delantera: Shimano, Microspline 148x12mm, Disc, 32H
- Maza trasera: Shimano, 110x15mm, Disc, 32H
- Rayos: 14g Black Stainless Steel
- Neumáticos: Delantero: Maxxis Assegai 29x2.5”, 3C MaxxTerra, EXO, Tubeless Compatible | Trasero: Maxxis Aggressor 29x2.5”, 3C Maxx Terra, EXO, Tubeless Compatible
- Desviador trasero: Shimano XT, 12 velocidades, SGS
- Shift Lever: Shimano SLX 12-Speed, I-Spec EV
- Volante: FSA Gradient, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Mego EXO Spindle, Boost Spacing
- Motos: MEGAEVO BB, 73mm BSA Threaded
- Cadena: KMC X-12 Silver and Black
- Cassette: Shimano SLX M7100, 12-Speed, 10-51T
- Freno delantero: Shimano SLX, 4-Piston Hydraulic Disc, 203mm Rotor
- Freno trasero: Shimano SLX, 4-Piston Hydraulic Disc, 180mm Rotor
- Maneta de freno: Shimano SLX Hydraulic, I-Spec EV
- Manillar: Marin 35mm 7000 Alloy Bar, 780mm Length, 5 Degree Up, 8 Degree Back
- Tee: Marin CNC Stem, 35mm Length, 35mm Bar Bore
- Puños: All New Marin Single Clamp Locking
- Dirección: FSA No 42/47, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
- Dropper: TranzX, YSP23JL, 1x Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm
- Sillin: Marin Trail Speed Concept Pro
- Extras: Bolt-On Thru-Axle
SERIES 3 ALUMINUMIM FRAME
Rift Zone alloy models feature Series 3 aluminum frames, with detailed forgings, highly manipulated tubes, and full internal cable routing with new braze-in ports, giving the rider a high feature and high-performing upgrade-worthy platform.
MULTITRAC SUSPENSION TECHNOLOGY
MultiTrac is an acclaimed suspension system, fine-tuned to have a balanced ride capable of absorbing big hits with an efficient pedaling platform. The rocker link provides a progressive leverage ratio for the rear shock for small bump sensitivity and the feeling of a long travel system on large drops and rocks. 130mm rear travel on all Rift Zone models.
MODERN TRAIL GEOMETRY
Trail geometry with 430mm chainstays, low bottom bracket, long top tube, and a slack 65.5° head angle make for a playful yet confidence-inspiring bike.
INTERNAL ROUTING
Rift Zone Alloy models sport full internal cable/hose routing in the front triangle, and all-new brazed-in cable ports, providing a clean and rattle free cable set up.
CHAINSTAY/SEATSTAY PROTECTORS & UDH ON ALLOY MODELS
Rift Zone models have enhanced chainstay and seat stay protectors for a quiet ride, and utilize SRAM's Universal Derailleur Hanger (UDH) to help future-proof the frame as well as allow for T-type drivetrains.
ENHANCED CHAINSTAY/SEATSTAY PROTECTION
Rift Zone models have prominent chainstay and seat stay protectors for a quiet ride that also protects the paint finish.
